PTN450 Hollow Rotary Actuator-Hollow Rotary Actuator

PTN450 Hollow Rotary Actuator

Product Introduction :

1. Product size: 450

2. Ratio range: 10

3. Motor range: 3000W AC servo

4. Input installation size code: 35114.3M12200LR124.5(ratio:10); 42114.3M12200LR124.5(ratio:10);

Size :

450

Speed ratio range:high precision

Precision range: 10

Performance advantages
Parameter details
Moment of inertia
Standard installation size

Product specifications:

1.work objects can be directly locked: the rotating disk surface can directly lock the work objects to improve the convenience of workpiece loading;

2.convenient wiring: the rotary platform is of hollow design, which is convenient for wiring or piping;
3.high accuracy: the positioning accuracy is less than 1arcmin; The repetition accuracy can reach ± 5arcsec;

4.stable operation: the panel rotates smoothly and smoothly, and the cutting and positioning is fast

Product size:
